The CE-607 is designed to fit 2009- 2016 FLH/FLT models without an oil cooler. Starting in 2009 the single front motor mount was replaced with two side motor mounts. This allows us to eliminate the regulators tall legs giving the regulator a clean custom look. This regulator will not fit with low mount oil coolers. If you have an oil cooler see the CE-608.

Features
Controls voltage on Harley-Davidson and Buell alternators, unlike other rectifiers or regulators that dump to ground and cause maximum stator current and higher temperatures
Cycle Electric rectifying regulators block current to control voltage; this reduces stator current, resulting in low temperature and less drag on the motor, which means more efficient operation
Made in the USA

Replacement Part for OEM Number: 74505-09

Note: Will not fit models with low-mount oil cooler.

Specs
Product Name Rectifier Regulator
Color/Finish Black
Amps 45 A / 60 A
Battery Voltage 12 V
Units Each
Riding Style Street

Package info
Weight 2.7 lbs
Height 5.21
Length 7.62
Width 5.25

2015-2016 Harley-Davidson FLHTK Ultra Limited
2015-2016 Harley-Davidson FLTRXS Road Glide Special
2015-2016 Harley-Davidson FLHTCUL Electra Glide Ultra Classic Low
2015-2016 Harley-Davidson FLRT Freewheeler
2015-2016 Harley-Davidson FLHTKL Ultra Limited Low
2015 Harley-Davidson FLTRX Road Glide
2014-2016 Harley-Davidson FLHXS Street Glide Special
2011-2013 , 2016 Harley-Davidson FLTRU Road Glide Ultra
2011-2013 Harley-Davidson FLTRX Road Glide Custom
2010-2014 Harley-Davidson FLHTK Electra Glide Ultra Limited
2010-2011 Harley-Davidson FLHXXX Street Glide Trike
2009-2016 Harley-Davidson FLHR Road King
2009-2016 Harley-Davidson FLHTCU Electra Glide Ultra Classic
2009-2016 Harley-Davidson FLHTCUTG Tri Glide Ultra
2009-2016 Harley-Davidson FLHX Street Glide
2009-2013 Harley-Davidson FLHTC Electra Glide Classic
2009-2013 Harley-Davidson FLHRC Road King Classic
2009-2010 , 2016 Harley-Davidson FLTR Road Glide
2009 Harley-Davidson FLHT Electra Glide Standard

Installation Instructions
CE-607
The CE-607 regulator is designed for use on 2009-2016 FLH-FLT.

Remove Old Regulator
1) Remove the two-¼ 20 nuts that hold the regulator on.
2) Remove the wire clamps and save for reassembly.
3) Lift the regulator off the mounting studs and tilt it forward to access the wire connections.
4) Remove the locking clips and disconnect the stator and battery plugs.

Install New Regulator
1) Remove the retaining clips from the stator and battery connectors on the new regulator. Save them for reassembly.
2) Place the regulator on the mounting studs. Reuse the stock ¼’ nuts to fasten the regulator to the frame.
3) Connect the stator and battery plugs.
4) Install one plug-retaining clip on each plug.
5) Check the routing of all wires to be sure they are not in a vulnerable position. Keep the wires away from the motor mount. It moves with the motor and may wear through the insulation . Be sure the wires are not in the very bottom of lower frame or they will get pinched if you bottom out.
6) Start the motor and check battery voltage. Battery voltage should run 14.4 to 14.6 volts.
