Note:
Before replacing regulator, test stator for shorts to ground and proper AC output. If the stator is bad, a complete charging system upgrade part is recommended.
For '97-'98 FLH/FLT see 2112-1823
For '99-'01 FLH/FLT see 2112-1820

Cycle Electric Rectifying Regulator
Controls voltage on alternators, unlike other rectifiers or regulators that dump to the ground and cause maximum stator current and higher temperatures
For more efficient operation, Cycle Electric rectifying regulator blocks current to control voltage, which reduces stator current, resulting in low temperature and less drag on the motor
Designed for use on all FL models with a 38 or 48 amp alternator
Standard black
Amps: 38/48
OEM # 74505-97
Made in the U.S.A.

Included Items:
(1) Rectifier/Regulator
(3) Wiring harnesses
(3) Black cable ties
Instructions

Specs
Product Name Rectifier Regulator
Color/Finish Black
Amps 38 A / 48 A
Battery Voltage 12 V
Units Each
Riding Style Street

Package info
Weight 3.32 lbs
Height 5.35
Length 7.75
Width 5.35

1999-2001 Harley-Davidson FLHRCI Road King Classic
1998-2001 Harley-Davidson FLTR Road Glide
1998-2001 Harley-Davidson FLTRI Road Glide
1998-1999 Harley-Davidson Road King EFI FLHR
1998-1999 Harley-Davidson Electra Glide Ultra Classic FLHTCU
1997-2001 Harley-Davidson FLHTC Electra Glide Classic
1997-2001 Harley-Davidson FLHTCI Electra Glide Classic
1997-2001 Harley-Davidson FLHTCUI Electra Glide Ultra Classic
1997-2001 Harley-Davidson FLHR Road King
1997-2001 Harley-Davidson FLHT Electra Glide Standard
1997 , 2000-2001 Harley-Davidson FLHRI Road King
1997 Harley-Davidson FLHTCU Electra Glide Ultra Classic
