$439.95
The Mikuni HSR smoothbore flat slide carburetors provide unmatched throttle response and power output, and is easy bolt on horsepower for all Harley-Davidson Big Twin, Twin Cam, Sportster, and Buell motorcycles. An aftermarket carburetor from Mikuni will transform your Harley into the motorcycle it should be!
• Mid-range jetting for easy bolt on installation to a wide variety of bikes
• Comes without intake manifold, cables and air cleaner to permit tailoring to specific applications
• Standard finish body gives this HSR a natural look on most stock bikes
NOTE: Hooks up to most factory Harley throttle and choke cables.
NOTE: Developed for Harley engines, but can be used on just about anything requiring this size and type of carburetor.
Note: Airbox adapter H17-005 must be ordered separately
Made in Japan
Carburetor Application General
Carburetor Size 45mm
Carburetor Type Flat Slide
Carburetor Mount Spigot
Carburetor Intake Bell Diameter 65mm
Engine Side Sizing 49mm
Idle Location Left
Accelerator Pump Yes
Carburetor Depth 93mm
Carburetor Height 170mm
Slide Type TM42/08
Main Jet Series N100.604
Pilot Jet Series VM28/486
Needle Jet Series 723
Needle & Seat Type 786-27001
Air Jet Series BS30/97
Pump Nozzle Series TM42/11
Float Height 18mm
