DYNA 2000TC PROGRAMMABLE DIGITAL PERFORMANCE IGNITION MODULE
Single-fire, fully programmable performance ignition
Sixteen programmable advance curves in three groups: stock to slightly modified motors, heavily modified motors and insanely modified motors
Eight rev limiter settings in 250 rpm steps from 5750-7250 rpm
All functions offer full digital accuracy
Compatible with stock and performance coils – less than 1 ohm resistance
Coil current constantly monitored to provide constant full-spark energy
Uses all stock sensors and connectors
Built-in reverse battery and spike protection
Data recording includes total engine hours, time wide-open throttle, longest time operating at wide-open throttle, max rpm, seconds near rev limit and number of engine starts
PC programmability makes possible an eight-point, fully definable, wide-open throttle curve and a fully definable part-throttle curve, programmable rev limit in 50 rpm steps, 0-5 programmable dead-cranking revs, total of +/- 10° rear cylinder offset, programmable rev limiter, and security lock out (pin # activated)
Sold each by jtscycleparts
Made in the U.S.A.

SPECIFICATIONS

MADE IN THE U.S.A. Yes
MODEL 2000TC
PACKAGING Each
PROGRAMMABLE Yes
REV LIMITER Yes
SPECIFIC APPLICATION Yes
STYLE Performance Replacement
TYPE Ignition Module

FITS THE FOLLOWING MODELS

Year Model
2000 - 2003 Deuce - FXSTD
1999 - 2000 Dyna Convertible - FXDS-CONV
1999 - 2003 Dyna Low Rider - FXDL
1999 - 2003 Dyna Super Glide - FXD
1999 - 2003 Dyna Super Glide Sport - FXDX
2001 - 2003 Dyna Super Glide T-Sport - FXDXT
1999 - 2003 Dyna Wide Glide - FXDWG
1999 - 2003 Electra Glide Classic - FLHTC
1999 - 2003 Electra Glide Standard - FLHT
1999 Electra Glide Ultra Classic - FLHTCU
2000 - 2003 Fat Boy - FLSTF
2000 - 2003 Heritage Classic - FLSTC
2000 - 2003 Heritage Springer - FLSTS
1999 - 2002 Road Glide - FLTR
1999 - 2003 Road King - FLHR
2000 - 2003 Softail Night Train - FXSTB
2000 - 2003 Softail Springer - FXSTS
2000 - 2003 Softail Standard - FXST
