Features
Kit includes stator, rotor, black rectifying voltage regulator and mounting hardware
Made in the U.S.A.

Notes: Adding electrical accessories increases amperage usage. When doing so, it is important to consider amperage ratings of switches and wires. If you draw too many amps through a switch or wire, it will heat up and may burn. Fuses and breakers are sized to protect wiring and switches. DO NOT CHANGE 30A MAIN BREAKER TO A 50A BREAKER. THE SWITCHES AND WIRING WILL NOT BE PROTECTED.

Specs
Product Name Charging System
Type Alternator
Number of Teeth 38 Teeth
Amps 15 A / 27 A
Battery Voltage 12 V
Alternator Phase Type -
Units Kit
Riding Style Street

Package info
Weight 12.2 lbs
Height 9.47
Length 10.38
Width 9.55

2012-2013 Harley-Davidson XL1200V Seventy-Two
2011-2012 Harley-Davidson XR1200X
2010-2013 Harley-Davidson XL1200X Forty-Eight
2010 Harley-Davidson XR1200
2009-2013 Harley-Davidson XL1200C Sportster 1200 Custom
2009-2012 Harley-Davidson XL1200N Sportster 1200 Nightster
2009-2011 Harley-Davidson XL1200L Sportster 1200 Low
2009 Harley-Davidson XL1200R Sportster 1200 Roadster
