Features

• Top end gasket kit includes correct base, head gasket and cylinder O-rings as well as other top end specific O-rings or seals needed for R&R of top end
• MLS head gaskets promote an even torque load across the gasket sealing surface, providing less bore distortion and better piston ring seal for more power
• 4-stroke head gaskets are made to perform on today’s highest-output 4-stroke naturally aspirated and boosted machines, utilizing a multi-layered steel design with the outer layers being embossed and coated with a Viton rubber coating; these head gaskets are designed to meet the demands of today's high-horsepower, high-cylinder-pressure engines
• EST (Extreme Sealing Technology) gasket kit includes embossed stainless steel head, base and rocker gaskets covered with a proprietary rubber material
• Head gasket material allows heat to be drawn away from the combustion ring and dissipated evenly across the gasket surface to eliminate hot spots and gasket failure
• Made in the USA

Specs
Material MLS (Multi-layer Steel)
Thickness 0.69 mm / 0,027"
Bore Size 98.00 mm
Units Kit
Product Name Gasket Kit
Riding Style ATV
Type Top End

Package info
Weight 0.15 lbs
Height 0.1
Length 7
Width 6

2020-2023 Yamaha YFM 700 Grizzly EPS XT-R 4x4
2019-2023 Yamaha YFM 700 Grizzly EPS SE 4x4
2019-2023 Yamaha YFM 700 Kodiak EPS 4x4
2019-2023 Yamaha YFM 700 Kodiak 4x4
2019-2023 Yamaha YFM 700 Kodiak EPS SE 4x4
2018-2023 Yamaha Viking 700 Ranch EPS EFI
2016-2023 Yamaha Viking 700 VI Ranch EPS EFI 4x4
2016-2023 Yamaha YFM 700 Grizzly EPS 4x4
2016 Yamaha YFM 700 Grizzly 4x4
2015-2023 Yamaha Viking 700 VI EPS EFI 4x4
2015-2017 Yamaha Viking 700 VI SE EPS EFI 4x4
2015-2016 Yamaha Viking 700 VI 4x4
2014-2023 Yamaha Viking 700 EPS 4x4
2014-2020 Yamaha Viking 700 4x4
2014-2017, 2019 Yamaha Viking 700 SE EPS EFI
2013-2023 Yamaha Raptor 700 4x2
2009-2015 Yamaha YFM 700 FG Grizzly AT FI EPS SE 4x4
2008-2013 Yamaha YXR 700FI Rhino 4x4
2008-2009, 2013 Yamaha YXR Rhino 700 Special Edition
2008-2009, 2011-2012 Yamaha YXR Rhino 700 Sport
2008 Yamaha Rhino 700 Ducks Unlimited Edition
2007-2023 Yamaha Raptor 700R SE 4x2
2007-2015 Yamaha YFM 700 Grizzly AT FI 4x4
2007-2015 Yamaha YFM 700 FGP Grizzly AT FI EPS 4x4
2007 Yamaha Raptor 700R GYTR Edition 4x2
2006-2023 Yamaha Raptor 700R 4x2
